Chapter 7: Accessorizing the Ductless Enclosure
Product Service 1-800-522-7658
56
7. Remote Blowers – used to exhaust to the outside only.
6" nominal ID inlet blower has a 1/4 hp direct drive motor and corrosion-resistant
epoxy-coated steel housing and wheel with blower inlet of 6.00" ID. Outlet dimensions
are 4.25" x 7.38" OD.
CFM @ Static Pressure-Inches of H
2
O
S.P. 0.0" 0.125" 0.25" 0.50" 0.75" 0.87"
CFM 595 560 515 420 300 167
Catalog # Description
Shipping Wt.
(lbs./kg.)
4863500 Remote Blower, 115 V, 60 Hz. 4.4 amps 35/16
4863501 Remote Blower, 115/230 V, 50 Hz, 5.6/2.8 amps 35/16
7053501 Explosion-Proof Remote Blower, 115 V, 60 Hz, 4.4 amps 40/18
10" nominal ID inlet blower has a 1/4 hp or 1/3 hp adjustable belt drive motor and
corrosion resistant epoxy coated steel housing and wheel with blower inlet of 10.87" ID.
Outlet dimensions are 5.5" x 10" OD.
Catalog # HP Description CFM@RPM Ranges at Static Pressure (inches of H
2
0)
Std. EP .25" .38" .50" .62" .75" .88" 1.00"
7068200 1/4
Remote Blower, 115V, 60
Hz, 4.4 A
540@800 410@800 350@870 390@970
7068300 1/4
Explosion Proof Blower
115V, 60 Hz, 4.5 A
720@950 760@1050 710@1060 620@1060
7068400 1/3
Remote Blower, 115V, 60
Hz, 6.1 A
760@1050 710@1060 620@1060 430@1060 460@1150 500@1220
7068500 1/3
Explosion Proof Blower,
115V, 60 Hz, 6.4 A
850@1130 825@1160 790@1190 770@1220 740@1260 640@1260
Dimensions
A 7.16"
B 7.00"
C 8.13"
D 6.81"
E 9.25"
Inlet 10.87" ID
Outlet 5.5"D x 10.0"W
Wheel 9.0" Dia.
