Server connection Echo Liquid Handling Platform (Server Version 3.1.x)
Network connection 10/100/1000 BaseT
Network protocol TCP/IP
User account
Labcyte (The client PC must have an account, with administrator privileges, that is accessible by
Labcyte Service and Support to service the Echo Liquid Handler system.)
The Echo Liquid Handler
Dimensions
53.8 cm width x 74.6 cm depth x 91.5 cm height (21.2 x 29.3 x 36.0 inches)
Echo Liquid Handler working
envelope (minimal installation
requirements)
Top: It is recommended to have 25.4 cm (10 in) above the instrument to remove the top cover
for servicing.
Front: It is recommended to have 40.6 cm (16 in) to allow sufficient clearance to load and
unload microplates by hand or by robot.
Side: It is recommended to have 121.9 cm (48 in) minimum on left and right sides to allow for
serviceability. The Echo Liquid Handler should have sufficient space to be rotated, otherwise
it will need to be removable for service.
Rear: It is recommended to have 30.5 cm (12 in) minimum behind the instrument to allow for
cables, hoses, tubing, and maintenance access. The coupling fluid bottle and optional caddy
fit within the rear clearance but can be relocated if necessary.
SMCChiller Dimensions
30 cm plus fittings width x 34 cm Depth x 18 cm Height (11.8 in x 13.4 in x 36.4 in). It is
recommended that the chiller be installed within 121.9 cm (48 inches) of the Echo Liquid
Handler.
Echo Client PC Additional space for the client PC, monitor, keyboard and mouse.
Other
Space must be allocated for:
l Any robotics in the system
l Workspace for microplates
