Labcyte Echo 655 - Chiller

Chiller
The SMC chiller (P/N 001-11149) is included with your Echo system. The SMC chiller utilizes a stainless steel thermoelectric (Peltier)
heat exchanger that regulates fluid temperature. The SMC chiller ships configured for operation with Echo Liquid Handlers:
Power Supply
The SMC chiller uses an auto switching power supply capable of running any single-phase
AC voltage in the range 100-240V, 50-60 Hz
A power cord suitable for the install location is provided
Maximum power is 500W
Temperature Control
The SMC chiller controls the temperature to +/- 0.02 °C by cooling and heating as
appropriate
The SMC chiller is air cooled
Ambient Operating Conditions
Temperature: 10-35 °C
Relative Humidity: 35-80%
Figure 2: SMCChiller
8
SITE PREP GUIDE | Echo® 650 Series Liquid Handler PN | 001-16480
