What You Will Be Receiving
Shipping Dimensions
The Echo Liquid Handler System is shipped in a crate with the following dimensions:
Instrument shipping crate weight 278 kg (577 lbs)
Instrument shipping crate
dimensions
114.3 cm width x 99.1 cm depth x 124.8 cm height (45 x 39 x 49.1 inches)
Accessory crates
Additional devices and/or consumables purchased together with the Echo Liquid
Handler may ship in the crate with the Echo Liquid Handler if there is sufficient room or
separately.
Echo Liquid Handler Components
The following components are included with the Echo Liquid Handler:
Vacuum line
HercoBraid, 9.5 mm (3/8 in) ID, 9.5 mm (5/8 in) OD (RyanHerco P/N 0512-072)
HFCD 17612 coupling body (Colder Products)
Vacuum Surge Tank
Assembly
(Optional) Usage dependent on configuration, but included with the Echo (P/N 001-5150)
Compressed air line
4.6 meters (15 ft) of polyurethane tubing; 6.35 mm (0.25 in) OD, 4.24 mm (0.170 in) ID (SMC
Pneumatics P/N TIUB07-BU)
LCD 13004 coupling body (Colder Products).
Coupling fluid bottle 1 L (P/N 001-5438)
Accessory kit Includes tubing and power cord for connecting the chiller (P/N 001-15272)
SMC chiller P/N 001-11149
Ethernet cable Crossover, 3 meters (10 ft)
Software Echo Client Utility installer provided on CD or USB drive
AC Power, Configuration, and Fuses
The following table describes the AC Power and Fuse requirements for the Echo Liquid Handler:
Voltage Frequency Power Fuse Part Number
100-120 V 50 Hz 8 A 250 VAC, 10 A, FAST 001-3966
200–240 V 50 Hz 5 A 250 VAC, 5 A, FAST 001-3967
Table 1: Electrical Configurations for the Echo Liquid Handler
Note: The power cord may need to be replaced with one conforming to local AC power receptacles. To determine which
AC power configuration you have, see the Power and Fuse Rating Label on the back panel of the Echo Liquid Handler.
