Mars-Mars PRO
User Manual
Code No. 9.900.900.710
U:\QA\Manualer\Arkiv\Manuals- Labogene-Origio-GKO\Manualer-WORD\ScanLaf\Mars Mars Pro manual-UK - rev. 06.doc
Page 30 af 34
T-5A
Ø5x20
Fan3
T-3,15 A
T-3,15 A
Ø5x20
Ø5x20
Option 1
T-1A
Ø5x20
Option 2
T-1A
Ø5x20
Option 3
T-1A
Ø5x20
Light
T-1A
Ø5x20
UV-light
T-1A
Ø5x20
Convertor
T-630mA
Ø5x20
Convertor
T-630mA
Ø5x20
Windows control
T-2A
Ø5x20
Windows up
T-1A
Ø5x20
Windows down
T-1A
Ø5x20
The fuses of the windows are located in the middle of the top of the cabinet behind a protective cover.
Equipment required
Small screwdriver for slotted screws and
Fuses (see the Instruction Manual).
Procedure for replacement of fuses (Authorized persons, only)
 Switch off the power
 Remove the protective cover
 Locate the burned fuse
 Replace the fuse
 Install the protective cover
 Switch on the power
12.4 UV GERMICIDAL LAMP – Fluorescent lamp
To open the service panel of the cabinet, set the window in highest position and you can open the
service panel.
