laerdal LCSU 4 User Guide

1 LCSU 4 Overview
English
4
Important Information
This User Guide covers two main versions of LCSU 4; one configured with 800 ml Canister, and one with 300 ml Canister. Both
versions can be purchased with or without RTCA compliance. Unless otherwise specified, the information in these User Guides
applies to all versions.
Note
Inspect all parts when unpacking. If there are signs of damage or parts are missing - immediately notify the seller. Do not
attempt to use the LCSU 4 if parts are damaged or missing.
LCSU 4 - 800 ml (Cat. No. 880051/880052)
Items Included:
• LCSU 4 Main Unit
• 800 ml Disposable Canister
• Patient Tube 1.8 m (6')
• Vacuum Tube
• AC/DC Adapter charger
• Battery
• User Guide
• Carry Bag (for 800 ml version)
• Wire Stand
LCSU 4 - 300 ml (Cat. No. 880061/880062)
Items Included:
• LCSU 4 Main Unit
• 300 ml Disposable Canister
• Patient Port
• Patient Tube 0.9 m (3')
• AC/DC Adapter charger
• Battery
• User Guide
• Carry Bag (for 300 ml version)
• The LCSU 4 Main Unit is the same for both versions. Each version can easily be converted to the other Canister option by
ordering additional parts.
• For latest version of Spare Parts, Accessories and Consumables, visit www.laerdal.com
Control Panel
Vacuum
Regulator
Battery Cover
12V DC
Power Input
Patient Port
Disposable Canister
(300 ml) with Internal Filter
Vacuum Port
Connector
(Canister - white)
Vacuum Inlet
Connector
(LCSU 4 )
Vacuum Tube
Wire Stand
Vacuum Inlet
Disposable
Canister (800 ml)
with Internal Filter
Anti-Spill
Connector
