20-18071 Rev A
Replacing the Pneumothorax Bladders
Replace the pneumothorax bladders after multiple
decompressions.
Open the torso skin as described in Opening Torso.
1. Lift the chest plate to expose pneumothorax bladders.
2. Slide the bladder(s) out.
3. Disconnect the tube(s).
4. Discard used bladder(s).
5. Select new bladder.
6. Slide bladder into place.
7. Reconnect tube to the bladder.
8. Replace chest plate.
