laerdal SimMan 3G PLUS - Page 70

20-18071 Rev A
Replacing Arm(s)
1. Unzip the torso skin.
2. Move the torso skin to one side.
3. Lift up the chest plate.
4. Unscrew the arm bolt.
5. Disconnect cables as shown and feed them out of the arm
socket.
6. To install a new arm, reverse the process.
