CIRCUIT DIAGRAMS
10
N
K1M
4
3
PE
L1
N
1
2
L1
K1M
6
5
R
01
22
C1
1
N
02
2
11
A
A
3
4
1
2
K1M
C
B
40 Fm
CA
130 Fm
K1M
A1
A2
4
3
2 1
Hi
Hi
Ha
Ha
1 ~
01.10.2018
S0
EUGEN LÄGLER GMBH
Kappelrain 2
D-74363 Güglingen-Frauenzimmern
LED
LED
R1
8.6
kW
Selector switch
S1
Operation
Temperature
switch
M1
Motor 2.9 kW
220 V / 60 CPS
USA version
Start
Operation
Stop
Test
Fuse
6.2 A
Fuse
6.2 A
HUMMEL : Single-phase AC motor
®
2.9 kW / 220 V / 60 CPS
USA version
e-mail: info@laegler.com
Internet: http://www.laegler.com
Phone: 0049 - 7135 - 98 90 - 0
Fax: 0049 - 7135 - 98 90 - 98
Mains supply: 220 V / 60 CPS
Fuse protection of mains supply:
at least 20 A
C = Starting capacitorA
C = Running capacitorB
Ha = Main winding
Hi = Auxiliary winding
S0 = Emergency switch
R1 = Resistor
K1M = Contactor
Fuse
1A
LED
Light
1 ~
=
The circuit diagram valid for your machine is located in the motor switch box.
