SPARE PARTS HUMMEL
®
Item Part number Description
1 0965.1006.870 Screw
2 100.08.01.200 Sealing ring
3 100.08.00.100 Fan housing
4 100.10.00.200 Fan insert, complete
5 100.14.00.100 Intake duct
6 0933.1008.022 Screw
7 6797.1008.000 Washer
8 0912.1008.018 Screw
9 0127.1008.000 Spring washer
13 000.20.46.062 Wing screw
14 0125.1006.000 Washer
16 100.04.09.100 Lower rod, complete
17 000.17.20.081 Quick-fixing-fastener
18 100.04.01.200 Pivot pin
19 100.04.25.100 Spring with screw, complete
20 100.04.06.200 Notch plate
21 7500.1005.012 Screw
22 100.04.02.100 Spring tensioner, complete
23 100.05.00.200 Lateral wheel, complete
24 0931.1008.050 Screw
25 100.04.00.100 Lifting fixture
26 0125.1008.000 Washer
27 6330.1008.000 Nut
34 000.50.12.061 Nut
40 100.05.04.200 Wheel arm
41 100.05.29.100 Lateral wheel (from year of manufacture June 1999)
42 000.10.10.085 Washer
43 7984.1008.012 Screw
45 100.18.00.300 Rear wheel, complete
46 0934.1008.000 Nut
47 100.18.18.300 Tail axle housing, complete
48 100.18.29.105 Rear wheel (from year of manufacture 2002)
100.18.09.200 Rear wheel (up to year of manufacture 2001)
49 0912.1008.040 Screw
50 0914.0008.012 Grub screw
77
11
ATTENTION: Please specify in inquiries and spare part orders always the serial numbers of your machines ( Section 3.1)!
