Step Twenty Two: Both the left and right side lift panels have three bolt holes on
them. Take the matching side plate and secure to the outside of the panel.
(Photo shown is the inside of the panel) using (6) 1/4”*1/2” carriage bolts, (6)
1/4”*OD19*2t flat washers and (6) 1/4” hex nuts.
Step Twenty Three: Take the Octagon base panel with wheels and secure on to
the bottom of the drum using M4*12mm sheet metal thread bolts.
