4 CMS Components
4 CMS Components
4.1 MCC – Master Control Component (burner module)
4.1.1 For Your Safety
• Use password entry to protect parameters from unauthorised modification.
• Use external flame sensors only when these have been tested and approved according to
applicable local regulations see chapter 2.3.3.4 FFS/ION/Terminal - Flame Tolerance
Time.
• When connecting flame sensors approved for intermittent operation only, the MCC must
also be configured for intermittent operation (settings in P 301).
• The safety times can be accessed via the HMIs (UI400, GUI607/GUI610/GUI615).
4.1.2 Technical Data
Fig. 4-1 Figure of MCC
Fig. 4-2 MCC dimensional drawing
