4 CMS Components
4.7.5 Interfaces
Communication via LSB with CMS.
4.8 Graphic User Interface - GUI607/GUI610/GUI615
4.8.1 For Your Safety
• Only use with SELV supply voltage in accordance with DIN EN 60730.
• If this is not available, the GUI must be supplied by the 24 V output of the CMS.
4.8.2 Technical Data
4.8.2.1 GUI607
Fig. 4-38 GUI607 Fig. 4-39 Ensure unobstructed air circulation! >20 mm
