Lamtec UI400 User Manual

265
9 Faults
No. Description D1 D2 Extra
355 Ignition in mixed operation
FAT tries to ignite in a mixing curve Internal
information
Fuel train R = 0
Reset
356 Internal fault
– Reset fault
– If the fault still exists:
Send fault number and diagnostic code to the
technical support.
– Replace the device
Internal
information
0 R = 0
Power ON Reset
357 Internal fault
– Reset fault
– If the fault still exists:
Send fault number and diagnostic code to the
technical support.
– Replace the device
Internal
information
0 R = 0
Power ON Reset
380 Band failure: Setpoint is outside the expected range
The watchdog processor detects a band failure.
Setpoint or actual value of an actuator is not in the
expected range.
Setpoint minimum lower 12 bits: set-
point maximum
Channel number
in the bits above
bit 12
R = 0, 0, 0, 0
Reset
381 Actuator dynamics is missing
The ÜP has not detected the required dynamics for
at least one actuator.
Problem: The actual position of the actuator has not
changed in the last 24 hours.
– Check air damper and gas damper for jamming.
– In case of stiffness, clean the damper and
make it smooth running again.
– Check the function of the actuator without
damper and replace if necessary.
– Reset fault and switch mains voltage OFF
and ON again.
– If the error still exists, replace the device.
0: Actuator
dynamics
1: Correction
channel dynamics
Number of actua-
tor or correction
channel (starting
with 0)
R = 0
Reset
382 Monitoring data from the bus are missing
The watchdog processor requires certain data for
monitoring. These are read at the bus. Currently
required data are missing
Reason:
– Invalid channel configuration
– A non-existing channel is activated
– An inactive channel is marked in the channel
enable mask
1: Actual curve
set
3: Actual value,
channel no. in
P 2
4: Setpoint value,
Channel no. in
P 2
5: Firing rate
value
P 1 = 3 or 4,
Channel no.
(starting at 0)
P 1 = 5,
special fault code
R = 0
Power ON Reset
383 Invalid curve set selection
– Ensure that there is no fuel change during curve
set programming.
– Reset fault
00R = 0
Power ON Reset
