Land Pride RC15 Series - Driveline; Gearbox

22
Section 5 Maintenance and Lubrication
RC15, RC25, and RC35 Series Rotary Cutter 312-298M 9/25/08
Land Pride
Table of Contents
Driveline
Disconnect driveline from the tractor and slide apart
Quantity = Clean & coat the inner tube of the driveline with a
light film of grease and then reassemble
14191
20
Gearbox
Check oil level in the gearbox by removing the side plug in
the gearbox case. If the oil level is low, remove the top plug in
the gearbox case and fill with EP90 oil until oil flows from the
side port of gearbox case. Reinstall plugs and tighten.
Type of Lubrication: EP90 Oil
Quantity = fill until oil flows from the side port of gearbox
case.
NOTE: Do not overfill! Cutter should be level when
checking oil.
8
14252
