Land UNO - Installing the UNO Fibroptic Thermometer

User Guide User Guide
Page 5 Page 5
Fibroptic Thermometer
Fibroptic Thermometer
Thermometer Model U2_300/1100C-L U2_600/2000F-L
Temperature range: 300 to 1100°C 1100 to 2900°F
Wavelength: 1.6µm
Averager response time: Adjustable 5ms to 5s (0 to 95%)
Peak picker: Adjustable 1.5 to 30%/s decay
Emissivity: Adjustable 0.10 to 1.00
Field of view (nominal): 25:1
Target diameter:
A10 optic head: 4mm / 0.15in at 100mm / 3.9in
A25 optic head: 10mm / 0.39in at 250mm / 9.8in
A50 optic head: 23mm / 0.90in at 500mm / 19.6in
Accuracy:
Repeatability: 1°C / 2°F
Absolute: <1.0%K
Stability (Temp): 0.2°/°ambient
Stability (Time): <2°C / 4°F per year
Vibration: 3G Any axis 10 to 300 Hz
Humidity: 0 to 99% non condensing
Sealing: IP65
Ambient temperature:
Optic head: <200°C / 392°F
Lightguide: <200°C / 392°F
Detector:
Specified: 0 to 50°C / 32 to 122°F
Operating: -10 to 60°C / 14 to 140°F
CE: EN 50-082-2 (immunity)
EN 50-081-1 (emission)
IEC 1010 (safety)
Thermometer Model U2_300/1100C-L U2_600/2000F-L
Temperature range: 300 to 1100°C 1100 to 2900°F
Wavelength: 1.6µm
Averager response time: Adjustable 5ms to 5s (0 to 95%)
Peak picker: Adjustable 1.5 to 30%/s decay
Emissivity: Adjustable 0.10 to 1.00
Field of view (nominal): 25:1
Target diameter:
A10 optic head: 4mm / 0.15in at 100mm / 3.9in
A25 optic head: 10mm / 0.39in at 250mm / 9.8in
A50 optic head: 23mm / 0.90in at 500mm / 19.6in
Accuracy:
Repeatability: 1°C / 2°F
Absolute: <1.0%K
Stability (Temp): 0.2°/°ambient
Stability (Time): <2°C / 4°F per year
Vibration: 3G Any axis 10 to 300 Hz
Humidity: 0 to 99% non condensing
Sealing: IP65
Ambient temperature:
Optic head: <200°C / 392°F
Lightguide: <200°C / 392°F
Detector:
Specified: 0 to 50°C / 32 to 122°F
Operating: -10 to 60°C / 14 to 140°F
CE: EN 50-082-2 (immunity)
EN 50-081-1 (emission)
IEC 1010 (safety)
