Fibroptic Thermometer

1.5 Specifications

Thermometer Model U1_600/1600C-L U1_1100/2900F-L U1_800/2600C-L U1_1500/4700F-L

Temperature range: 600 to 1600°C 1100 to 2900°F 800 to 2600°C 1500 to 4700°F

Wavelength: 1µm

Averager response time: Adjustable 5ms to 5s (0 to 95%)

Peak picker: Adjustable 1.5 to 30%/s decay

Emissivity: Adjustable 0.10 to 1.00

Field of view (nominal): 25:1 75:1

Target diameter:

A10 optic head: 4mm / 0.15in at 100mm / 3.9in 1.3mm / 0.05in at 100mm / 3.9in

A25 optic head: 10mm / 0.39in at 250mm / 9.8in 3.3mm / 0.12in at 250mm / 9.8in

A50 optic head: 23mm / 0.90in at 500mm / 19.6in 6.7mm / 0.26in at 500mm / 19.6in

Accuracy:

Repeatability: <1°C / 2°F) <2°C / 4°F)

Absolute: <0.75%K <0.75%K

Stability (Temp): 0.2°/°ambient 0.3°/°ambient

Stability (Time): 2°C / 4°F per year 2°C / 4°F per year

Vibration: 3G Any axis 10 to 300 Hz

Humidity: 0 to 99% non condensing

Sealing: IP65

Ambient temperature:

Optic head: 200°C / 392°F

Lightguide: 200°C / 392°F

Detector:

Specified: 0 to 70°C / 32 to 158°F

Operating: -10 to 80°C / 14 to 176°F

CE: EN 50-082-2 (immunity), EN 50-081-1 (emission), IEC 1010 (safety)
