LANDA PG 8.913-910.0
19
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW - 4-2000, 4-3500 PARTS LIST
ITEM PART NO. DESCRIPTION QTY
66 8.707-152.0 NIPPLE, 3/8", MALE,
SSTEEL 1
67 9.802-817.0 Washer, 3/8" x 1" Steel 2
68 8.706-557.0 Bellows, LEG (Boot) 2
69 8.719-091.0 Spring, Foot Compression 2
70 8.719-954.0 Tube, Foot Bolt 2
71 9.802-778.0 Nut, 5/16" Whiz Loc Flange 3
72 8.757-203.0 SWIVEL, 1/2" M-NPTF x 3/4"
GHF 1
73 9.800-049.0 Label, Manufacturer’s 1
Cleaning Solution
74 9.802-710.0 Bolt, 5/16” x 1” NC, HH 2
75 9.802-727.0 Bolt, 3/8” x 1-3/4” Tap 2
76 9.802-959.0 Key, .247 x 2.125” 1
77 9.802-254.0 Hose, 1/4” Push-On, Fuel Line 4”
78 8.932-968.0 Label, Intended For Outdoor 1
79 9.802-744.0 Bolt 10mm x 20mm HH 4
80 9.802-816.0 Washer 7/16 Lock Split 4
81 9.804-016.0 Filter Screen Washer,
Garden Hose/30MESH 1
