LANDA PG 8.913-910.0
OPERATOR’S MANUAL
PRESSURE WASHER
22
EXPLODED VIEW - 4-4000, 5-3500 PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 8.757-257.0 Tee, Street 1/2" 1
2 9.803-098.0 Hanger, Hose & Wand 1
3 9.802-778.0 Nut, 5/16" Whiz Loc Flange 2
4a 9.802-254.0 Hose, 1/4", Push-On (4-40324E)
4 ft.
4b 9.802-254.0 Hose, 1/4", Push-On 19"
(4-40324E)
5 9.802-210.0 Clamp, Hose, UNI .46 - .54 4
(Honda)
6 9.197-003.0 Nut, 3/8" ESNA, NC 2
7 8.707-179.0 Nipple, Coupler, Fuel Line 1
(4-40324E)
8 8.900-247.0 Label, PG (Lexan) 1
9 8.900-415.0 Label, 5-3500 (Lexan) 1
8.900-413.0 Label, 4-4000 (Lexan) 1
10 8.758-290.0 Label Label Landa W/Instruction
and Warn 1
11 8.718-674.0 Bolt, 3/8-16 X 2-1/4",GR8.2
Whiz Loc 8
12 9.802-064.0 Grommet, 1/8" Rubber 4
13 9.804-081.0 Cushion, Pump (Thin) 2
14 8.706-656.0 Belt Guard, PG-Large, Plastic 1
15 9.802-126.0 Plug, 1/2" JIC, Flare 1
16 9.802-151.0 Swivel, 1/2" JIC Fem, Push-on 3
17 8.707-019.0 Push-on, 3/8" Male Pipe 1
18 8.913-902.0 Key Ring, #1 w/Landa 1
19 8.918-424.0 Hose, 3/8" X 25", 100R2, 1
Pres Loop
20 9.802-259.0 Hose, 1/2" Push-On 15”
21 8.758-460.0 Wheel 12 In. Rim Steel 2
22 8.712-354.0 Nozzle, SAQMEG, 1505, 1
Yellow 15° (5-3500)
8.712-355.0 Nozzle, SAQMEG, 2505, 1
Green 25° (5-3500)
8.712-356.0 Nozzle, SAQMEG, 4005, 1
White 40° (5-3500)
8.712-346.0 Nozzle, SAQMEG, 1504, 1
Yellow, 15° (4-4000)
8.712-347.0 Nozzle, SAQMEG, 2504, 1
Green, 25° (4-4000)
8.712-348.0 Nozzle, SAQMEG, 4004, 1
White, 40° (4-4000)
23 Engine, See Specifications Pages
ITEM PART NO. DESCRIPTION QTY
24 8.750-498.0 Muffler, Honda 1
GX630/GX660 Left
8.915-687.0 ▲ Deflector, Exhaust, Honda 1
9.802-867.0 Guard, Muffler, Briggs 1
(Vanguard)
9.802-868.0 ▲ Brace (Vanguard) 2
9.802-793.0 ▲ Nut Cage, 1/4" x 16 Gauge 4
(Vanguard) ▼
9.802-754.0 ▲ Screw, 1/4" x 1/2" HHNC, 4
Whiz Loc (Vanguard)
9.802-830.0 ▲ Screw, Hex 1/4-20 x 1/2" 4
(Vanguard)
25 9.803-631.0 Muffler, Exhaust Skid & PG, 1
Briggs (Vanguard)
8.718-156.0 Muffler, Honda, Left 1
26 8.920-223.0 Frame, PG, Large (5-35224E) 1
8.911-297.0 Frame, Large (4-40324E) 1
27 8.719-903.0 Bracket, Belt Tension 1
28 9.802-039.0 Elbow, 1/2" JIC, 3/8", 90° 1
29 8.757-203.0 SWIVEL, 1/2" M-NPTF x 3/4"
GHF 1
30 8.758-203.0 Protection pump 3/8" 145
Deg w/slnt 1
31 Pump, See Specifications Pages
32 8.757-655.0 Adapter steel 1/2 JIC (M)
x 3/8 NPTF (M) 1
33 8.757-200.0 Adapter brass 1/2 SAE (M)
x 1/2 NPTF (M) 1
34 8.707-152.0 NIPPLE, 3/8", MALE, SSTEEL 1
35 9.802-673.0 Key, Motor Shaft 1
(Vanguard)
9.802-959.0 Key, Motor Shaft (Honda) 1
36 Unloader, See Specifications Pages
37 9.802-870.0 Block, Unloader, 3/8" x 3/8" 1
Brass
38 9.802-807.0 Washer, 3/8" SAE, Flat 2
39 9.802-716.0 Bolt, 5/16" x 2", NC HH 4
(Vanguard)
9.802-728.0 Bolt, 3/8" x 2" 2
NC HH (Honda)
40 8.911-293.0 Bracket, Wide Foot 1
41 9.802-728.0 Bolt, 3/8" x 2" NC, HH 2
42 9.802-733.0 Bolt, 3/8" x 3-1/2", Tap 2
43 9.802-776.0 Nut, 5/16" ESNA, NC 3
44 9.197-003.0 Nut, 3/8" ESNA, NC 16
45 8.718-835.0 Nut, 5/8" JAM, ESNA, NF 2
47 8.718-980.0 Washer, 5/16" Flat, SAE 6
48 9.198-004.0 Washer, 3/8" Uss F/w Zinc 26
49 8.939-025.0 Handle, 1-1/4" Chrome 1
50 9.802-810.0 Washer, 5/8" Flat, SAE 4
To Next Page
