Landa PG5-3500E - Page 23

LANDA PG 8.913-910.0
23
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW - 4-4000, 5-3500 PARTS LIST
ITEM PART NO. DESCRIPTION QTY
52 8.920-250.0 Handle, Bumper 1-1/4" 1
Chrome Grab
53 9.802-789.0 Nut, 3/8" Hex, NC 2
54 8.906-774.0 Foot Assy w/out Bracket 2
55 8.706-557.0 Bellow, Leg (Boot) 2
56 8.718-684.0 Bolt, 3/8" x 5" NC, HH, Tap 2
57 9.802-817.0 Washer, 3/8" x 1" 2
58 9.802-819.0 Washer, 7/16" x 2-1/2" Zinc 2
59 8.719-091.0 Spring, Foot, Compression 2
60 8.719-954.0 Tube, Foot Bolt, PC 2
61 9.802-066.0 Pad, Soft Rubber 2
62 8.911-258.0 Holder, Battery, PG 1
63 8.719-901.0 Clamp, Battery, PG 1
64 8.719-905.0 Back Plate, Belt Guard, PG, Lg. 1
65 9.198-014.0 Washer, 5/16" x 1-1/4", Fender, 6
SAE (Vanguard)
9.802-811.0 Washer, 3/8" x 1-1/2" Fender 6
(Honda)
66 Engine Bushing, See Specifications Pages
67 Engine Pulley, See Specifications Pages
68 Pump Pulley, See Specifications Pages
69 Belt, See Specifications Pages
70 Pump Bushing, See Specifications Pages
71 8.757-653.0 Nipple steel hex 3/8" NPTF x
3/8" BSPP 1
72 8.757-262.0 Elbow brass 1/2 SAE (M) x
3/8 NPTF (M) 1
73 9.802-720.0 Bolt, 3/8" x 1" NC, HH 4
74 9.800-008.0 Label, Danger Cool Engine 1
75 8.706-940.0 Hose Barb, 1/4" Barb x 1/8" ML 2
(Fuel Tank Assy 4-40324E)
76 9.802-730.0 Bolt, 3/8" x 2-1/2" GR 5 ZN 2
77 8.707-178.0 Coupler, Fuel Line, Quick 1
(4-40324E)
78 8.757-199.0 HOSE BARB, 1/4" BARB x
1/4" M-NPTF, BRASS 1
79 8.751-294.0 Fuel Tank, 6 Gal (4-40324E) 1
80 9.800-006.0 Label, Hot 1
81 9.802-776.0 Nut, 5/16" ESNA (Vanguard) 4
9.197-003.0 Nut, 3/8" ESNA, (Honda) 4
82 8.718-980.0 Washer, 5/16" Flat 4
(Vanguard)
9.802-807.0 Washer, 3/8" Flat 4
( Honda)
83 8.750-737.0 Adapter, 3/8" x 1/4" 1
( Honda)
84 9.800-049.0 Label, Manufacturer’s Cleaning 1
Solution
ITEM PART NO. DESCRIPTION QTY
85 9.802-259.0 Hose, 1/2” Push-On 4”
86 9.802-710.0 Bolt, 5/16” x 1” NC, HH 2
87 8.932-968.0 Label, Intended For Outdoor 1
88 9.800-034.0 Label, Clear Lexan 1
89 9.802-727.0 Bolt, 3/8" x 1-3/4" Tap 2
90 8.751-101.0 Terminal, Ring Tongue, S6-38R 4
91 9.803-836.0 Wire, THWN 6 GA Red 17"
92 9.803-837.0 Wire, THNN, 6 GA Black 17"
93 9.802-744.0 Bolt 10mm x 20mm HH 4
94 9.802-816.0 Washer 7/16 Lock Split 4
95 8.718-781.0 Screw M5 X 8 X 40MM,
Pan Head (PG 4-40324E) 1
96 8.921-479.0 Label, CO10 Carb Compliance 1
97 9.804-016.0 Filter Screen Washer,
Garden Hose/30MESH 1
▲ Not Shown
