LANDA PG 8.913-910.0
OPERATOR’S MANUAL
PRESSURE WASHER
8
CAUTION
Never Use
:
• Bleach, chlorine products and other corrosive chemicals
• Liquids containing solvents (i.e. paint thinner,gasoline,oil)
• Tri-sodium phosphate products
• Ammonia products
• Acid-based products
These chemicals will harm the unit and will damage the
surface being cleaned.
Use manufacturer's detergents as recommended in manual
CAUTION
Never Use
:
• Bleach, chlorine products and other corrosive chemicals
• Liquids containing solvents (i.e. paint thinner,gasoline,oil)
• Tri-sodium phosphate products
• Ammonia products
• Acid-based products
These chemicals will harm the unit and will damage the
surface being cleaned.
Use manufacturer's detergents as recommended in manual
ASSEMBLY INSTRUCTIONS
STEP 1: Attach a 5/8" garden hose
to inlet connector. Minimum flow
should be 6 gpm.
STEP 2: Attach high pressure hose
to discharge nipple using quick
coupler. Lock coupler securely into
place by pulling back coupler col-
lar and inserting it onto discharge
nipple, then pushing collar forward
to lock in place.
STEP 3: Attach wand to spray
gun. Attach swivel connector on
discharge hose to spray gun us-
ing teflon tape on threads. Attach
swivel connector on high pressure
hose to spray gun using teflon tape
on threads. Engage safety latch to
prevent from triggering gun.
STEP 4: Remove oil plug on top of
pressure washer pump and replace
with dipstick supplied. (This may be
installed from the factory.)
Check oil level on sight glass on
back of pump. Oil should be visible
one half way up sight glass (30W
non-detergent).
STEP 6: Fill gasoline tank and
check engine oil.
Notice: Running the engine with
a low oil level can cause engine
damage.
STEP 5: Use a group U1, 12 volt, 30 amp hour battery (garden tractor
battery). Secure U1 battery to the battery holder using the battery clamp
provided.
To reduce the possibility of sparking attach the battery cables in the fol-
lowing order. First attach the positive battery cable (red) to the positive “+”
terminal of battery. Next, attach the negative battery cable (black) to the
negative “-” terminal of the battery. To disconnect the battery remove the
cables in the opposite order as installed.
WARNING: Wear eye, hand and skin protection when handling or
connecting battery.
WARNING: Batteries generate explosive gases during normal battery
operation. DO NOT expose the battery to flame or sparks as these
gases may ignite.
WARNING: Battery fluid is highly acidic. If battery fluid contacts skin
or clothing, wash immediately with soap and water. If battery fluid
enters eye, immediately flood eye with running cold water for at least
15 minutes and get immediate medical attention.
NOTE: The battery must be capable of accepting ring terminals.
NOTE: Battery and battery cable mounting bolts and nuts are not
provided.
High
Pressure
Hose
Wand
High
Pressure
Hose
Spray
Gun
Fuel
Cap
Electric Start
Models Only
Garden
Hose
To Next Page
