LANDA PG 8.913-910.0
OPERATOR’S MANUAL
PRESSURE WASHER
18
EXPLODED VIEW - 4-2000, 4-3500 PARTS LIST
ITEM PART NO. DESCRIPTION QTY
2 8.718-980.0 Washer, 5/16" Flat, SAE 6
3 8.758-290.0 Label Label Landa W/Instruction
and Warn 1
4 8.706-655.0 Guard, Belt, PG Small, Plastic 1
(4-2000)
8.706-656.0 Guard, Belt, PG Large, Plastic 1
(4-3500)
5 9.802-066.0 Pad, Soft Rubber 2
6 9.802-819.0 Washer, 7/16" x 2-1/2", Zinc 2
7 8.718-674.0 Bolt, 3/8-16 X 2-1/4",GR8.2
Whiz Loc 8
8 9.802-811.0 Washer, 3/8" x 1-1/2", Fender 1
9 Engine Bushing, See Specifications Pages
10 Pump Bushing, See Specifications Pages
11 Engine Pulley, See Specifications Pages
12 Pump Pulley, See Specifications Pages
13 Belt, See Specifications Pages
14 8.911-286.0 Back Plate, Belt Guard, 1
PG Small (Landa Pump)
8.933-026.0 Back Plate, Belt Guard, Large 1
(PG4-3500)
15 8.900-412.0 Label, 4-3500 Lexan 1
8.900-409.0 Label, 4-2000 Lexan 1
16 Engine, See Specifications Pages
17 8.932-993.0 Cushion, Pump, Thin 1
18 9.802-125.0 Plug, 1/4" JIC 1
19 9.802-153.0 Swivel, 1/4" JIC Fem, Push-on 1
20 9.803-098.0 Hanger, Hose & Wand 1
21 9.802-154.0 Plug, Push-on, Oil Drain 1
22 9.197-003.0 Nut, 3/8" ESNA, NC 12
23 9.198-004.0 Washer, 3/8" Uss F/w Zinc 18
24 9.802-810.0 Washer, 5/8" Flat, SAE 4
25 8.718-835.0 Nut, 5/8" Jam, ESNA, NC 2
26 8.718-684.0 Bolt, 3/8" x 5" NC 2
27 8.911-289.0 Frame, PG/PE Small (4-2000) 1
8.920-223.0 Frame, Large Belt Drive 1
(4-3500)
28 8.925-055.0 Handle, Bumper, Grey 1
29 9.802-733.0 Bolt, 3/8" x 3-1/2", Tap 2
30 9.802-728.0 Bolt, 3/8" x 2" 2
31 8.900-247.0 Label, PG (Lexan) 1
32 8.754-186.0 Qh Wheel Assy, 10" Gray Steel 2
Rim W/Tube
8.758-460.0 Wheel 12 In. Rim Steel
(4-3500) (4-2000) 2
33 8.719-905.0 Bracket, Belt Tension 1
34 9.800-034.0 Label, Clear Lexan 1
ITEM PART NO. DESCRIPTION QTY
35 9.802-789.0 Nut, 3/8", Hex, NC 3
36 8.925-056.0 Grab Assy, Grey 1
37 9.802-064.0 Grommet, Rubber (4-3500) 4
(4-2000) 5
38 8.712-346.0 Nozzle, SAQCMEG 1504, 1
Yellow (4-3500)
8.712-347.0 Nozzle, SAQCMEG 2504, 1
Green (4-3500)
8.712-348.0 Nozzle, SAQCMEG 4004, 1
White (4-3500)
8.712-362.0 Nozzle, SAQC Meg 1506, 1
Yellow (4-2000)
8.712-363.0 Nozzle, SAQC Meg 2506, 1
Green (4-2000)
8.712-364.0 Nozzle, SAQC Meg 4006, 1
White (4-2000)
39 Pump, See Specifications Pages
40 9.802-811.0 Washer, 3/8" x 1-1/2" Fender 6
41 9.802-870.0 Block, Unloader, 3/8" x 3/8", 1
1.25, Steel
42 9.802-728.0 Bolt, 3/8" x 2", NC HH 2
43 8.757-653.0 Nipple steel hex 3/8" NPTF
x 3/8" BSPP 1
44 8.757-262.0 Elbow brass 1/2 SAE (M)
x 3/8 NPTF (M) 1
45 9.802-720.0 Bolt, 3/8" x 1" NC 2
46 8.757-655.0 Adapter steel 1/2 JIC (M) x 3/8
NPTF (M) 1
47 9.197-003.0 Nut, 3/8" ESNA, NC 2
48 9.802-807.0 Washer, 3/8" SAE, Flat 2
49 8.757-616.0 Elbow steel 1/2 JIC (M)
x 3/8 BSPP (M) 1
50 8.918-424.0 Hose, 3/8" x 25", 2 Wire 1
Pressure Loop
51 Unloader, See Specifications Pages
52 8.757-200.0 Adapter brass 1/2 SAE (M) x
1/2 NPTF (M) 1
53 8.757-257.0 TEE, STREET 1/2" 1
54 9.802-151.0 Swivel, 1/2" JIC Fem, Push-On 2
56 9.800-006.0 Label, Hot/Caliente 1
57 9.800-008.0 Label, Danger Cool Engine 1
58 9.802-259.0 Hose, 1/2", Push-On 15”
59 9.802-720.0 Bolt, 3/8" x 1" NC, HH 1
60 9.802-067.0 Bumper Pad, Engine 1
61 9.802-807.0 Washer, 3/8" SAE, Flat 4
62 9.197-003.0 Nut, 3/8" ESNA, NC 4
63 9.802-776.0 Nut, 5/16" ESNA 3
64 8.758-203.0 Protection pump 3/8" 145
Deg w/slnt 1
65 8.911-293.0 Bracket, Wide Foot 1
To Next Page
