Carrying out assembly
2
1
3
2a
1. Place the three ame covers (2, 2a) into the recesses
so that the pointed triangular edges are pointing
upwards.
Take care that the ame covers are placed so
that the high side edges (2a) lie directly next to
the infrared burner (3). They protect the infrared
burners from damage caused by ames.
4
6
2. Insert the three grills (4) and the cooking plate (6).
5
3. Insert the warming racks (5) into their guide slots.
6
4. Unscrew the cap for the ignition knob (6), insert an AA
battery (negative pole rst) and then carefully replace
the cap.
The assembly process is now complete.
