Assembly
Before starting
Here are a few tips to help you assemble your barbecue quickly and successfully:
• Check that no parts are missing by placing all of the individual parts on an empty surface (we reserve the right to make
minor technical alterations, such as the content of the small parts bag).
• If, despite careful factory checks, a component should be missing, please contact our customer service department (see
last page). We will immediately attend to your request.
Remove all of the packing material.
• Sort out the small parts, as some of the screws and bolts, for example, are very similar and can be easily confused.
• You will need the following for the assembly:
• A medium sized screwdriver and suitable spanners (fork, ring or box spanner).
– Another person who can help you with the assembly.
• You will need a at spanner (AF17) to connect the gas cylinder.
CAUTION
• Only use tools that are intact and suitable for the job at hand. Worn or unsuitable
tools will not allow you to tighten the nuts and bolts suciently and may damage
them so that they can no longer be turned.
• Always t all connecting elements (screws, bolts, nuts, etc.) as shown in the follow-
ing illustrations. If you misplace a connecting element, replace it with an appropri-
ate part. Only by doing this can you ensure that the construction is strong and safe.
• Be sure to follow the instructions in the specied order!
• Read the text for each step before carrying it out, as useful information is sometimes
only provided at the end of the section.
Even if you are not experienced at DIY, assembly does not generally take longer than one hour.
