Landmann 42170 - Step 19: Flame Tents, Grates, Warming Rack; Step 20: Grease Tray and Box; Step 21: Igniter Battery Installation

13
Assembly Instructions
+
–
21
J
V
Unscrew the igniter button cap on the control panel of
grill body (J). Insert the AA battery (V) so the positive
end of battery is facing outward.
From back of grill, first slide grease tray (T) into slots
on the grill body (J) until it lines up with the bottom of
the grill. Then place the grease box (U) into the slot on
the bottom of the grease tray.
1919
R
S
Q
First insert flame tents (Q), then cooking grates (R)
and warming rack (S) in that order.
J
U
T
2020
