Laney TFX2 - Parts List

BLT Industries
15/05/2003
TFX2E
TFX2 65W GUITAR AMPLIFER EURO/UK Quantity
007979 TFX2 CHASSIS ASSY 230V 1.0000
005005 NEW TYPE MAINS SOCKET-UL 1.0000
005511 5MM SOLDER TAG 2.0000
005136 TFX1/2/3 - 10W IDC SIGNAL CABLE ASSY DWG 3414 1.0000
005530 20mm T1A FUSE 1.0000
005558 100mm TIE WRAP 5.0000
005665/CP 12mm KNOB C/P 15.0000
006130 TF200 230V MAINS TRANSFORMER 1.0000
007985 9390 TFX2/TFX3 PREAMP ASSY 1.0000
001305 2K2 5% RESISTOR 3.0000
001306 10K 5% RESISTOR 6.0000
001309 1M 5% RESISTOR 2.0000
001310 100K 5% RESISTOR 17.0000
001312 4K7 5% RESISTOR 4.0000
001315 47K 5% RESISTOR 2.0000
001316 22K 5% RESISTOR 2.0000
001317 39K 5% RESISTOR 2.0000
001318 6K8 5% RESISTOR 1.0000
001319 15K 5% RESISTOR 6.0000
001326 3K3 5% RESISTOR 5.0000
001327 1K 5% RESISTOR 4.0000
001331 33K 5% RESISTOR 1.0000
001336 470K 5% RESISTOR SMD 1206 1.0000
001706 330R 5W RESISTOR 1.0000
002013 10UF 50V CAPACITOR 1.0000
002024 2.2UF 63V RADIAL 1.0000
002037 220N 5MM BOX POLY CAPACITOR 63V 4.0000
002038 330N 5MM BOX POLY CAPACITOR 63V 2.0000
002414 1NF 100V 5mm 2.0000
002415 2.2NF 100V 5mm 1.0000
002416 3.3NF 50V 5mm 2.0000
002419 100NF 63V 5mm 2.0000
002420 22NF 100V 5mm 7.0000
002421 10NF 100V 5mm 2.0000
002602 47PF 50V 10% COG 3.0000
002603 100PF 50V 10% COG 1.0000
002604 270PF 50V 10% COG 1.0000
002605 470PF 50V 10% COG 2.0000
002831 100N 50V CERAMIC CAPACITOR 0805 12.0000
003014 15V 1.3W ZENER 1.0000
003022 3mm GREEN LED 1.0000
003033 3mm LED RED 2.0000
003500 BAS16 DIODE 2.0000
003508 34072 IC (SMD TL072) 5.0000
003905 7805 IC 1.0000
004061 6mm 22K LIN POT 2.0000
004062 6mm 100K LOG POT 7.0000
004063 6mm 2K2 LIN POT 2.0000
005002 MONO JACK SOCKET 1.0000
005017 2P 2W PUSH SWITCH 1.0000
005066 2 WAY LOCKING HEADER 2.0000
005079 IDC PCB PLUG 10-WAY 1.0000
005089 SWITCH CAP OVAL+WINDOW 3.0000
005127 P16 7MM DIA HOLE POT BRKT 1.0000
005300 PIGGY BACK PUSH SWITCH 3.0000
005503 7.5mm ROUND BLACK BUTTON 4.0000
009390 TFX2/TFX3 PREAMP PCB ISSUE 3 1.0000
007986 9392 TFX2 FX CONTROL PCB ASSY 1.0000
003022 3mm GREEN LED 2.0000
004061 6mm 22K LIN POT 2.0000
005036 6 WAY LOCKING HEADER 2.0000
005079 IDC PCB PLUG 10-WAY 1.0000
005127 P16 7MM DIA HOLE POT BRKT 1.0000
005129 40W PIN HEADER(20+20STRAIGHT) 1.0000
005131 16 POSITION GRAY CODE ROTARY SWITCH 2.0000
009392 TFX2 FX CONTROL PCB ISSUE 3 1.0000
007990 9389 TFX2 OUTPUT PCB ASSY 1.0000
001003 1K .25W RESISTOR 2.0000
001006 4K7 .25W RESISTOR 1.0000
001010 47K .25W RESISTOR 1.0000
001013 22K .25W RESISTOR 1.0000
001014 10K .25W RESISTOR 3.0000
001017 47R .25W RESISTOR 2.0000
001021 100R .25W RESISTOR 1.0000
001200 470R .5W RESISTOR 1.0000
