TECHNICAL DATA CONT’D
PROBE RESISTANCE
TEMP RESISTANCE VOLT DROP TEMP RESISTANCE VOLT DROP
70° 556 Ω
1.11
290° 881 Ω
1.76
80° 569 Ω
1.14
300° 897 Ω
1.79
90° 583 Ω
1.17
310° 914 Ω
1.83
100° 596 Ω
1.19
320° 931 Ω
1.86
110° 610 Ω
1.22
330° 948 Ω
1.90
120° 623 Ω
1.25
340° 965 Ω
1.93
130° 637 Ω
1.27
350° 983 Ω
1.97
140° 651 Ω
1.3
360° 1000 Ω
2.00
150° 665 Ω
1.33
370° 1018 Ω
2.04
160° 678 Ω
1.36
380° 1036 Ω
2.07
170° 694 Ω
1.39
390° 1054 Ω
2.11
180° 709 Ω
1.42
400° 1072 Ω
2.14
190° 724 Ω
1.45
410° 1090 Ω
2.18
200° 739 Ω
1.48
420° 1109 Ω
2.22
210° 754 Ω
1.51
430° 1127 Ω
2.25
220° 769 Ω
1.54
440° 1146 Ω
2.29
230° 785 Ω
1.57
450° 1165 Ω
2.33
240° 800 Ω
1.60
460° 1184 Ω
2.37
250° 816 Ω
1.63
470° 1204 Ω
2.41
260° 832 Ω
1.66
480° 1223 Ω
2.45
270° 848 Ω
1.70
490° 1243 Ω
2.49
280° 864 Ω
1.73
500° 1263 Ω
2.53
NOTE
Probe is factory checked at 350 °F. Must be completely disconnected from circuit board when measuring
probe resistance. Display will read “HELP” if probe is open or unplugged. Any probe resistance can be
multiplied by 2 milli-amps (.002) to determine voltage drop.
