Model No: RT36A, RT36B, RT36C, RT36D, RT36E, RT36F, RT36G
COMMERCIAL & MARINE ELECTRIC RANGE TOP
Fig No Part No Qty Description Application
13
P9-70701-35
(Black),
P9-70701-35-2
(Red)
1 KNOB ASSY 850° B ALL RT36F, RT36J
P9-70701-41
(Black),
P9-70701-41-2
(Red)
3
KNOB ASSY 6 HEAT EGOTK
ALL RT36B AND RT36D
4 ALL RT36A AND RT36C, RT36F
6 ALL RT36E
Y9-70701-16
(Black),
Y9-70701-16-2
(Red)
2
KNOB ASSY 450o A
ALL RT36A; RT36C-440 VM,480 V AND VM
3 ALL RT36D; ALL RT36B; RT36C-208 V AND VM, 240 V AND VM
PS-70700-09-1 6 KNOB ASSY-INDUCTION RTI36E
14
2J-31601-01
1
PILOT LT 250V 6LEAD BLK
RT36F-208V & VM, RT36F-240V & VM, RT36F-208V
2 RT36A-208V & VM, 240V & VM, RT36C-208V & VM, 240V & VM
3 RT36B-208V & VM, 240V & VM, RT36D-208V & VM, 240V & VM
2J-31601-02
2
PILOT LT 480V 6LEAD BLK
RT36A-440VM, 480V & VM, RT36C-440VM, 480V & VM
3 RT36B-440VM, 480V & VM, RT30D-440VM & 480V
14 Y9-31601-02-1 3 PILOT LT 480V W/TIN CLIP PHANT RT36D 480 SUB
15
P9-RF21-415-1 2 PAN ASSY (304 S/S)
ALL RT36A V, ALL RT36B V, ALL RT36C V, RT36D-208V & 240V,
ALL RT36E V
PS-60102-W1232 1 RF21 MARINE PAN ASY-RIGHT
ALL RT36A VM, ALL RT36B VM, ALL RT36C VM, RT36D-208VM
& 240VM & 440VM, ALL RT36E VM
P9-RF21-750 2 PAN WLDMENT ASSY-INDUCTION RTI36E
16 P9-50300-44-1 1 GRAB BAR ASSY 36 RANGE
ALL RT36A VM, ALL RT36B VM, ALL RT36C VM, ALL RT36D
VM, ALL RT36E VM
17 M9-60102-290 1 MARINE PAN ASSY - A/L
ALL RT36A VM, ALL RT36B VM, ALL RT36C VM, ALL RT36D
VM,ALL RT36E
18 P9-RF21-803 1 WINDOW - CP RF21 RT36B-480VCP
19 P9-RF21-800 1 DOOR ASSY - CP RT36B-480VCP
20 P9-50306-25
2
WIRE BRACKET ASSY TILT-UP
ALL RT36A
3 ALL RT36D
1 ALL RT36G
21 P9-50306-33
3
ELEM TERMINAL GUARD
ALL RT36D
2 ALL RT36A
1 ALL RT36G
22
P9-50300-22
2
208-240 V 3/16 BULB HOLDER
ALL RT36A 208, 240 V AND VM
3 ALL RT36D 208, 240 V AND VM
P9-50300-43
2
480 V 3/16 BULB HOLDER
ALL RT36A 440VM, 480 V AND VM
3 ALL RT36D 440VM, 480 V AND VM
1 ALL RT36D 440VM
23
P9-50300-41
2
ELEM PAN ASSY (W/SNOUT) 5KW
RT36A 208, 240 V AND VM
3 RT36D 208, 240 V AND VM
P9-50300-43 1 480 V 3/16 BULB HOLDER ALL RT36G
24 P9-50300-42
2
ZIG ZAG ASSY (W/SNOUT) 5KW
ALL RT36A
3 ALL RT36D
1 ALL RT36G
PARTS LIST October 4, 2012
