Model No: RT36A, RT36B, RT36C, RT36D, RT36E, RT36F, RT36G
COMMERCIAL & MARINE ELECTRIC RANGE TOP
Fig No Part No Qty Description Application
1
P9-50401-09
1
RANGE PLATE ASSY 1” X 2’ ALL RT36A V
P9-50401-02 RANGE PLATE ASSY 1/2” X 2’ ALL RT36A VM
3
P9-50401-03
1
RANGE PLATE ASSY 1/2” X 3’ ALL RT36D VM
P9-50401-11 RANGE PLATE ASSY 1/2” X 3’ ALL RT36D V
P9-50403-10 RANGE PLATE ASSY 1” X 3’ RT36D1
P9-RF21-740 1 TOP GLASS ASSY-36” INDUCTION
RTI36
PS-71300-22 AR GLASS ONLY - 36” INDUCTION
4
P9-50302-301
1
SEARAIL ASSY 3’ {RF&500} ALL RT36E-VM, RT36F-VM
P9-50302-303-1 SEARAIL ASSY 1’ {ADD} SK ALL RT36A AND RT36C VM
5
2N-11120-12
2
ELMNT TK 208V 2600W
RT36A-208V & VM, RT36C-208V, RT36A1-208V
4 RT36F-208V & VM, RT36J-208V
6 RT36E-208V & VM
2N-11120-13
2
ELMNT TK 240V 2600W
RT36A-240V & VM, RT36C-240V & VM
4 RT36F-240V & VM
6 RT36E-240V & VM
2N-11120-14
2
ELMNT TK 480V 2600W
RT36A-440VM, 480V & VM, RT36C-440VM, 480V & VM
4 RT36F-480VM
6
RT36E-440VM, 480V & VM
2N-11120-18 ELMNT TK 380V 2000W RT36E-380V
2N-11120-26 6 INDUCTION MOD-2600W 208/240 RTI36E
6
P9-50300-82-1
1
EGO PLATE FRM ASY PHANT
RT36A-208V & VM, 240V, ALL RT36C
3 ALL RT36E
P9-50300-83 2 EGO FRENCH HOT PLATE RT36F-480VM
7
PS-11010-341
1
HOTPLATE 208V 5000W CAST
RT36F-208V & VM, RT36J-208V
2 RT36C-208V
3 RT36B-208V & VM
PS-11010-351
1
HOTPLATE 240V 5000W CAST
RT36F-240V & VM
3 RT36B-240V, RT36C-240V & VM, RT36F-240VM
PS-11010-361
1
HOTPLATE 480V 5000W CAST
RT36F-440VM & 480VM
3 RT36B-440VM, 480V & VM, RT36C-440VM, 480V & VM
8 2C-21003-02 10 SCRW SECRTY 1/4-20 2-EAR RT36B-480VCP
9 P9-RF21-820 2 HOT TOP HLDER ASY CORR. PKG RT36B-480VCP
10
2E-30304-09
2
SWTROT 6 HEAT+OFF208/240V
RT36A-208V & VM, 240V, 440VM, 480V & VM, RT36B-440VM,
ALL RT36C
4 ALL RT36G
6 ALL RT36E
2T-30402-08
1
STAT ADJ 450o 72 C/T
ALL RT36G
2 ALL RT36A
3 ALL RT36D
2T-30402-23
3
STAT ADJ 850° 48C/T NAK
ALL RT36B
2 ALL RT36C
1 ALL RT36F, RT36J
2E-30304-14 6 CONTROL MODULE-INDUCTION RTI36E
11
P9-RF21-304
1
CONTROL PANEL H ALL RT36E
P9-RF21-305 CONTROL PANEL C&G ALL RT36C AND RT36G
P9-RF21-306 CONTROL PANEL A&D ALL RT36A AND RT36D
12 Y9-50300-63 1 MARINE PAN LATCH ASSY
ALL RT36A VM, ALL RT36B VM & VCP, ALL RT36C VM, RT36D-
208VM & 240VM & 440VM, ALL RT36E VM
PARTS LIST July 24, 2012
