Chapter 1:
Introduction
Thank you for choosing Lanner FW-7525. FW-7525 is
a fanless desktop network security system utilizing the
cutting edge capabilities of the Intel Rangeley platform
(Based on Intel Atom C2000 series 2-core/4-core CPU,
System-On-Chip solution). The Rangeley platform
is built-in Intel QuickAssist Crypto acceleration, it
targets at Entry-level UTM, Firewall, VPN, IPS and WAN
optimization applications in SMB environment. The
system built-in 4 or 6 GbE LAN ports, 1 x Non-ECC
DDR3 1333/1600 DIMMs, and 36/60 W power adapter.
Features:
Intel Atom C2358/C2518/C2558 CPU built-in Intel •
QuickAssist Crypto acceleration
Fanless design•
Rangeley Platform•
Fanless design, compact form factor•
Intel AES-NI new instructions, improves security •
without slowing response times
Support up to 8 GB DDR3 Memory•
Intel i210AT LAN controller•
Support Gen.2 LAN Bypass function (model A, C, •
and D only))
Intel Virtualization Technology•
Intel C2000 series processor comes with an enhanced
cryptographic/content processing acceleration via
integrated Intel®QuickAssist Integrated Accelerator
with the following instructions:
–Bulk Encryption: AES, DES, 3DES, RC4
–Hash: SHA-1, MD5; SHA-2 (SHA-224, SHA-256, SHA-
384, SHA-512);
Authentication: HMAC, AES-XCBC, AES-CCM, and
AES-GCM
–Public Key Exchanges: RSA, DH, DSA, ECC
Form Factor Desktop
Platform Processor Options
2-core Intel® Atom
Processor C2358 2-core,
C2518 4-core, or C2558
2.4GHz 4-core CPU (Code-
named “Rangeley”)
BIOS AMI BIOS 16MB
System
Memory
Technology
Single Channel Non-ECC
DDR3 1333/1600 MHz,
1.5 V
Max. Capacity 8 GB
Socket 1 x 204-pin SO-DIMM
OS Support Linux Kernel 2.6 or above
Storage
HDD/SSD Bays 1 x 2.5” SSD kit
CompactFlash 1 x Type II CompactFlash
Networking
Ethernet Ports 4 or 6 x GbE RJ45 onboard
Bypass
1 pairs Generation 2 (on
model FW-7525A/C only)
Controllers
2 x Intel i210AT, 4 x
Marvell 88E1543
Ethernet Modules N/A
Management Port N/A
I/O Interface
Reset Button
1 x reset button
Software reset by default
Console 1 x RJ45
USB 2 x USB 2.0
IPMI via OPMA
slot
N/A
Display N/A
Expansion
PCIe 1 x Mini-PCIe
PCI N/A
Cooling
Processor Fanless
System Fanless
Environmental
Parameters
Temperature,
ambient operating
/ storage
0 ~ 40º C / -20~70º C
Humidity (RH),
ambient operating
/ ambient non-
operating
5~90%, non-condensing /
5~95%, non-condensing
Miscellaneous
LCD Module N/A
Watchdog Yes
Internal RTC with
Li Battery
Yes
Physical
Dimensions
Dimensions
(WxHxD)
177 x 44 x 145.5 mm
Weight 1.2 kg
Power
Type/Watts 36W/60W Power Adapter
Input 100~240V@50~60Hz
System Specifications
