NCA-1515 User Manual
8
The NCA-1515, a desktop network appliance powered by Intel® Atom® C3000 (codenamed Denverton)
CPU, features robust performance and Intel’s QuickAssist Technology, offering cryptographic acceleration
and commercial-grade LAN functions in a 231mm x 200mm x 44mm (WxDxH) form factor.
Intel® Atom® C3000 (Denverton)
Max. 4x GbE RJ45 w/ 1 Pair of Gen3 Bypass, 2x GbE SFP w/ LED & 2x GbE RJ45 (See SKU)
2x 260-pin SODIMM (by SKU), DDR4 2400/2133/1866MHz ECC SODIMM, Max. 32GB
1x RJ45 Console, 2x USB 2.0, 1x Onboard EMMC 8G, 2x Nano SIM for M.2
2x Mini-PCIe (PCIe / USB 2.0), 1x M.2 2242 B Key (USB 3.0)
Your package contains the following items:
1x NCA-1515 Network Appliance
1x Power Adapter
1x Power Cable (the provided plug type will vary by region)
4x Rubber Pads
Note:
(1) If any component is missing or damaged, please contact your dealer immediately for
assistance. (2) The supplied power adapter and power cable are dedicated to this product only;
do not use them with devices other than this model.
C3758, 2x DDR4 ECC SODIMM, 4x GbE RJ45 w/ 1 Pair of Gen3 Bypass, 2x GbE SFP w/ LED
& 2x GbE RJ45, w/BMC, 60W Adapter
C3558, 2x DDR4 ECC SODIMM, 4x GbE RJ45 w/ 1 Pair of Gen3 Bypass & 2x GbE SFP w/
LED, w/ BMC, 60W Adapter
C3308, 1x DDR4 ECC SODIMM, 4x GbE RJ45 w/o Bypass, 36W Adapter
Note: Intel® Atom® C3000 processor supports only 2400Mhz RAM. (To use memory with lower
frequencies, please check with your sales representative)
1U Rack-mount kit (Ear Bracket)
HDD Kit
Wall Mount Kit
