Chapter 3 Hardware Installation
15
With the Wall-mount Kit, this system can be fixed on the wall surface. Please contact Lanner‘s sales
representative for purchasing this kit.
What’s in the Wall-mount Kit?
Check the kit contents for the following items:
1x pair of Wall Brackets
1x Screw Pack
1. Flip over the system; fix both wall brackets
onto the bottom with four screws as shown in
the picture.
2. On the wall, measure the exact place where
you want to hang the system and drill four
holes.
3. Insert the wall plugs into the holes, and then
insert the long screws into the wall screws.
M3 x 19.5mm
(The demonstrated screw type can fit in general
drywall or shelves. Please identify the wall type
and select the suitable fixing approach to fix this
system to the wall, and consult a qualified trained
person if you are unsure.)
