Lanner NCA-1516 - Installing Optional PoE Module Kit; PoE Module Kit Components; Prepare System for PoE Module Installation; PoE Module Slot and Screw Replacement

NCA-1516 User Manual
26
The motherboard supports one PoE module slot. Please follow the steps below to install the PoE kit.
1. The PoE Module Kit includes:
1x PoE Module
3x Spacer standoff pillar studs
1x Power Adapter
2. Power off the system and open the chassis
cover.
3. Locate the PoE Module slot placement.
4. Remove the three (3) screws
5. Replace the three (3) screws with the
spacer standoff pillar studs.
PoE Module
Power Charger
Spacer Standoff
Pillar Studs
3
4
5
