Lanner NCA-5210 - System Specifications

15
Form Factor
1U Rackmount
Platform
Processor Options
Intel® Core
TM
i7/i5/i3 or Xeon® E3-
1200v5/v6 or Pentium® or Celeron®
(Skylake/Kaby Lake)
CPU Socket
1x LGA1151
Chipset
Intel® C236
Security Acceleration
N/A
BIOS
AMI SPI Flash BIOS
System Memory
Technology
DDR4 2,400MHz ECC (by CPU) or non-ECC
UDIMM
Max. Capacity
64GB
Socket
4x 288-pin DIMM
Networking
Ethernet Ports (By SKU)
1x GbE RJ45
SKU A: 8x GbE RJ45
SKU B: 12x GbE RJ45, 4x GbE SFP
SKU C: 4x NIC Modules Slots
Bypass
SKU A: 4x Gen3 bypass
SKU B: 6x Gen3 bypass
NIC Module Slot
SKU A & B: 2x NIC slots
SKU C: 4x NIC slots
LOM
IO Interface
1x RJ45 (Optional)
OPMA slot
Yes
I/O Interface
Reset Button
1x Reset Button
LED
3x LED (Power, Status, Storage)
Power Button
1x ATX Power Switch
Console
1x RJ45 Console Port
USB
2x USB 2.0
LCD Module
2x 20 Character LCM, 4x Keypads
IPMI via OPMA slot
Yes
Power input
AC Power Inlet
Storage
HDD/SSD Support
1x 3.5” or 2x 2.5” SATA HDD/SSD
Onboard Slots
1x mSATA
Expansion
PCIe
1x PCIe*4/8 FH/HL (By Project)
mini-PCIe
N/A
Miscellaneous
Watchdog
Yes
Internal RTC with Li Battery
Yes
TPM
N/A (Default); Yes (Optional)
Cooling
Processor
Passive CPU Heatsink
System
4x Cooling Fans with Smart Fan
Environmental Parameters
Temperature
0~40°C Operating
-20~70°C Non-Operating
Humidity (RH)
5-90°C Operating
5-95°C Non-Operating
System Dimensions
(WxDxH)
438 x 525 x 44 mm
Weight
15kg
Package Dimensions
(WxDxH)
790 x 600 x 220 mm
Weight
16kg
Power
Type/Watts
300W 1+1 ATX Redundant PSUs
Input
AC 90V – 264V @47-64Hz
Approvals and Compliance
RoHS, CE/FCC Class A, UL
