Socket0 Configuration
Feature
Options
Description
Socket 0
PcieBr1D00F0
None
Settings related to PCI Express Port 1A
Socket 0
PcieBr1D02F0
None
Settings related to PCI Express Port 1C
Socket 0
PcieBr2D00F0
None
Settings related to PCI Express Port 2A
Socket 0
PcieBr2D02F0
None
Settings related to PCI Express Port 2C
PCIe Slot 1 PCIe Slot 2
(1A~1D) (2A~2D)
