Lanner NCA-5710 - System Specifications

Chapter 1: Product Overview
14
Form Factor
1U 19“ Rackmount
Platform
Processor Options
Intel® Xeon® Processor Scalable Family
(Skylake-SP)
CPU Socket
2x LGA3647
Chipset
Intel® C621/627
Security Acceleration
Intel® QuickAssist Technology (By SKU)
BIOS
AMI SPI Flash BIOS
System Memory
Technology
DDR4 2666 MHz REG DIMM
Max. Capacity
384GB
Socket
12x 288pin DIMM
Networking
Ethernet Ports
4x GbE RJ45 or 4x 10G SFP+ Lewisburg
Internal MAC
Bypass
Depends on NIC module specifications
NIC Module Slot
4
LOM
IO Interface
1x RJ45 (Optional) *Share with ETH0
OPMA slot
IPMI Chip Onboard (SKU B & C)
I/O Interface
Reset Button
1
LED
Power/Status/Storage
Power Button
1x ATX Power Switch
Console
1x RJ45, 1x mini USB
USB
2x USB 3.0
LCD Module
N/A (Optional)
Display
1x Internal Pin Header
Power input
AC power inlet on PSU
Storage
HDD/SSD Support
2x 2.5”Internal Bays
Onboard Slots
1x M.2
Expansion
PCIe
1x PCI-E*16 FH/HL (Optional)
mini-PCIe
N/A
SIM card Slot
N/A
Miscellaneous
Watchdog
Yes
Internal RTC with Li Battery
Yes
TPM
Yes (Optional)
Cooling
Processor
Passive CPU heat sink
System
6x individual hot-swappable cooling fans
with smart fan
Environmental Parameters
Temperature
0~40ºC Operating
-40~70ºC Non-Operating
Humidity (RH)
5~90% Operating
5~ 95% Non-Operating
System Dimensions
(WxDxH)
610mm x 438mm x 44mm
Weight
24kg
Package Dimensions
(WxDxH)
841mmx588mmx215mm
Weight
18kg
Power
Type/Watts
850W 1+1 ATX Redundant PSUs
Input
AC 100~240V @47~63 Hz
Approvals and Compliance
RoHS, CE/FCC Class A
