1. Check the package contents of the Slide Rail Kit. The kit shall include the following items:
1x pack of M4X4L screws (for securing the sliding rail on the system)
2 x Slide Rails
The rail consists of the following parts:
Attaching the Rail Brackets
2. Unpack a slide rail and slide the
Inner Channel all the way to the
end.
3. Stretch the Rail Bracket to the
fullest.
4. Remove the Rail Bracket from the
Inner Channel by pushing the
Release Tab on the Rail Bracket
outwards while sliding it out.
Outer Channel
Inner Channel
Rail Bracket
Release Tab
Rail Lock
Release Tab
