Chapter 2: Hardware Installation
40
5. Align the Rail Bracket to the side of the chassis and make sure the screw-holes on it match and properly
engage the four buttons on the side panel as shown in the picture.
6. Carefully pull the Rail Bracket backward to have the buttons locked into the four screw holes as shown
in the picture.
7. Repeat Steps 5-6 to attach the Rail Bracket to the other side of the chassis.
Front
Rear
Aligning
Left Bracket
Buttons
Right Bracket
Locked
