NCA-5710 User Manual
102
Feature
Options
Description
PCI-E Port
Auto
Enable
Disable
In auto mode the BIOS will remove the EXP port if
there is no device or errors on that device and
the device is not HP capable. Disable is used to
disable the port and hide its CFG space.
Hot Plug Capable
Enable
Disable
This option specifies if the link is considered Hot
Plug capable.
Surprise Hot Plug
Capable
Enable
Disable
This option specifies if the link is considered
Surprise Hot Plug capable.
Link Speed
Auto
Gen 1 (2.5 GT/s)
Gen 2 (5 GT/s)
Gen 3 (8 GT/s)
Choose Link Speed for this PCIe port
PCI-E Port
DeEmphasis
-6.0 dB
-3.5 dB
De-Emphasis control (LNKCON2[6]) for this PCIe
port.
PCI-E Port Max
Payload Size
Auto
128B
256B
Set Maxpayload size to 256B if possible
PCI-E ASPM
Support
Auto
L1 Only
Disable
This option enables / disables the ASPM (L1)
support for the downstream devices.
Compliance Mode
Enable
Disable
Disable/Enable Compliance Mode for this PCIe
port
Extra Bus Reserved
0
Extra Bus Reserved for bridges behind this Root
Bridge.
Reserved Memory
40
Reserved Memory Range for this Root Bridge.
Reserved Memory
Alignment
1
Reserved Memory Alignment (0 - 31 bits)
Reserved
Prefetchable
Memory
40
Reserved Prefetchable Memory Range for this
Root Bridge.
Reserved
Prefetchable
Memory Alignment
1
Reserved Prefetchable Memory Alignment (0 - 31
bits)
64 bit Reserved
Prefetchable
Memory
40
64 bit Reserved Prefetchable Memory Range for
this Root Bridge.
64 bit Reserved
Prefetchable
Memory Alignment
1
64 bit Reserved Prefetchable Memory Alignment
(0 - 31 bits)
Reserved I/O
4
Reserved I/O (4K/8K/12K/16K/20K) Range for this
Root Bridge.
