Lanner NCA-5710 - Installing NIC Modules

Chapter 2: Hardware Installation
32
NCA-5710 comes with 4 NIC Ethernet module slots for network bandwidth expansion. Please follow the
steps for installation.
1. On the front panel, select a NIC Ethernet module slot.
2. Loosen the two lock-screws.
3. Remove the door and locate the
socket for module insertion.
1
2
2
3
Socket
