Chapter 3: Software Setup
75
Hardware
RTS/CTS
overflow.
VT-UTF8 Combo Key
Support
Disabled
Enabled
Enables VT-UTF8 Combination Key Support for
ANSI/VT100 terminals
Recorder Mode
Disabled
Enabled
With this mode enabled, only text will be sent. This
is to capture Terminal data.
Resolution 100x31
Disabled
Enabled
Enables or disables extended terminal resolution
Legacy OS
Redirection
Resolution
80x24
80x25
On Legacy OS, the Number of Rows and Columns
supported redirection.
Putty KeyPad
VT100
LINUX
XTERM86
SCO
ESCN
VT400
Selects FunctionKey and KeyPad on Putty.
Redirection After
BIOS POST
Always Enable
BootLoader
When Bootloader is selected, Legacy Console
Redirection is disabled before booting to legacy
OS. When Always Enable is selected, then Legacy
Console Redirection is enabled for legacy OS.
Default setting for this option is set to Always
Enable.
