Technical Specifications UDS10/UDS100 User Guide
56
UDS100 Technical Specifications
CPU, Memory Lantronix DSTni-LX 186 CPU, 48 MHz
1 MByte FLASH ROM
256 Kbytes zero wait state RAM
Serial Interface Female DB25 connector (DCE pinout)
Speed software selectable (300 to 115 kBaud)
Software selectable RS-232C or RS-422/485
Network Interface
10/100 RJ45 Ethernet
Power Supply External adapter included
120 VAC USA
100 - 240 VAC Universal with regional connectors
Power Input 9-30 VDC or 9-24 VAC (1W maximum)
Dimensions
Height: 2.3 cm (0.9 in)
Width: 6.4 cm (2.5 in)
Depth: 9.0 cm (3.5 in)
Weight 0.35 Kg (0.8 lbs)
Temperature
Operating range: 5° to 50° C (41° to 122° F)
Storage range: -40° to 66° C (-40° to 151° F)
Relative Humidity Operating: 10% to 90% non-condensing, 40% to 60% recommended
Storage: 10% to 90% non-condensing
