Larius 3000 - Correct Procedure of Decompression

13
3000
English
O CORRECT PROCEDURE OF DECOMPRESSION
• Lock the safety (O1) clamp of the gun.
• Stop the engine turn the knob (O2) to OFF position.
• Unlock the safety clamp (O3).
• Place under the gun the paint recovery.
At the end lock the safety clamp again.
• Push the levers (O4) to discharghe the pressure.
•
Open the discharge valve ( O5 ) to release the remaining
pressure.
WARNING:
If the equipment is still under pressure after performing the operations above described
because of the nozzle or the flexible hose clogged, proceed as follows:
• Loosen very slowly the gun nozzle.
• Release the clamp.
• Point the gun at the container of the product and press the trigger to release
pressure.
• Loosen very slowly the fitting of connection from the flexible hose to the gun.
• Clean or replace the flexible hose and the nozzle.
O1
O2
O5
O3
O4
