VANG SET UP
1. Attach boom to mast.
2. Attach the Gnav bar to the mast.
. Attach Gnav
the boom.
. The Gnav tackle ( supplied with Gnav bar )
hould be attached by taking the only free
nd of the black / green fleck rope and
he top spinlock
6. Attach the pulley and shackle on the
black / green rope to the lower D ring /
3
to
4
s
e
feeding this thru the sheave on the top of the
boom.
5. Feed this rope thru the pulley on the aft
face of the mast and then to t
leat. c
webbing on the mast.
