LaserLine 211B - Page 17

Connection diagram
BLUE-BLACK
YELLOW x2
VIOLA
BLACK
RED
LIGHT BLUE
GREY-BLACK
GREEN-BLACK
Negative or positive input
do bonnetors /
see pag.26 function16
+12 Vdc
GND
Positive input
ACC
Positive output
Indicator light
Relé 1 n.o
Relé 1 n.c
Relé 1 com.
RED-BLACK
BROWN-BLACK
YELLOW-BLACK
Rel 2 n.oé
Rel 2 n.cé
Rel 2 com.é
CLOSURE
COMMAND
Max 10A
OPENING
COMMAND
Max 10A
see pag. 19-20
see pag. 19-20
GREY
Negative or positive input
Trunk
see pag.26 function15
WHITE-BROWN
Negative output
see pag.26 function18
Max 1A
3° button
or
ALARM
TRIGGER
WHITE
Negative output
Max 1A
ALARM
ARMED
BLUE-BROWN
BLUE-BROWN
+
+
YELLOW-GREEN
GREEN
Relé COM
Relé NO
Max 7+7 A
BLACK
RED
BLUE
AERIAL
Riceiver + LED
Ø 10mm
BUILT-IN
RELE
Max 10A
LED
see pag.26
function13
ultrasonic
module
Pag.17
Siren 909TF
KIT 211
Siren 919
KIT 211B
