11- AUTOMATIC ACTIVATION OF THE LOCKING CLOSURE
Allow to close automatically the centrlaized locking 5sec after the ignition is turned ON if all doors are
closed.
unlocked The doors will be automatically when the ignition key is turned .OFF
IMPORTANT NOTE : PROGRAM THIS FUNCTION ONLY FOR THE CASE IN WHICH THE
CAR IS EQUIPPED WITH AN ORIGINAL POWER LOCKING SYSTEM “” CRASH SENSOR
THAT IS ACTIVATED IF AN ACCIDENT OCCURS NO INERTIA SWITCH IF NOT ( ). , A
SIMILAR ONE AVAILABLE ON THE MARKET MUST BE INSTALLED THE .
MANUFACTURER WILL BE NOT BE HELD RESPONSIBLE IF USERS DO NOT COMPLY
WITH THIS NOTE .
13- :INTERNAL RELAY OUTPUT DURING AN ALARM -
Allow to use the internal rele in two di ernt way:ff
- Relé to block starting
- Active during alarm cycle (set also function 9)
15- IBONNET NPUT
Allow to change the polarity of the alarm input :
- Negative mode: when the bonnet is open, the alarm detect a negative signal
- Positive mode: when the bonnet is open, the larm detect an positive signal or missing a negative.a
ù16- INPUTDOORS AND TRUNK
Allow to change input polarity
- Negative mode: when the doors or trunk is open, the alarm detect a negative signal
- Positive mode: when the doors or trunk is open, the alarm detect an positive signal or missing a
negative.
17- SYREN PEAKER OR CODED
Allow to choose the right syren’s protcol:
- 909 for KIT 211
- 908 for KIT 211B
18- TOUTPU ALARM OUTPUT LIGHT BOOT / -
Allow to choose how work the output WHITE-BROWN wire:
- ALARM TRIGGERED / CAR FINDER: Negative output during the alarm cycle, usefull to connect an
external GPS locator and receive the alarm.
Moreover The 3rd button, if the alarm is armed, set the«CAR FINDER»: the indicators light will
activated, pressing button 3 (not depending 24 programming).FUNCTION
The indicators light activation stop automatically after 10 minutes or disarm the alarm.
This function doesn't allow the selection of the 8 FUNCTION
- OUTPUT LIGHT / BOOT: after set the function 8, the output is active for 20 or 1 seconds
19- COMFORT FUNCTION AUTOMATIC OR MANUAL ( ) required function 4 enable
For cars equipped with COMFORT locking, it is possible to obtain window closing when the alarm is
armed in two dif rent waysfe
- MANUAL: during arming/disarming, keep press the remote control button until the the windows will
close/open to the desired height, then release the button.
- AUTOMATIC: when the alarm is armed the windows will be completely closed.
20- DOOR SENSOR EXCLUSION IN THE FIRST 15 SEC. AFTER THE ALARM IS TURNED ON.
For cars equipped with a ceiling light with delayed shutdown, it is possible to delay the "doors open"
test (see page 23) Is mandatory connecting the ceiling light wire to the BLUE wire.
By activating the function, during pre-arming period (led ON) if the doors are not closed steadily
properly, or the ceiling light delays a few seconds to turn o the alarm for the first 15seconds does ff,
not sound the usual 3 beeps.
After 15 seconds, if the persists on light blue wire, there will be a continuous alert.signal
Pag.26
Programmable functions
