LMH Series Rotary Lasers • 29
5. SPECIAL FEATURES
This detector has a unique memory feature, which preserves the last
position of the laser beam if the detector is moved out of the plane of
laser light, as well as built in electronic fi ltering for bright sunlight and
electromagnetic interference. Three distinct audio tones (high,
on-grade, and low) assist targeting from a distance.
Features speaker Off, Loud
(105 dBA) and Louder (125+
dBA), fi ne, medium, and coarse
beam resolution settings, and
front and back LCD displays.
Seven distinct channels of
information (Fig. 2) indicate
the position of the detector in
the plane of laser light. As you move the detector
closer to the center, the arrows fi ll in to indicate the laser position.
6. CARE OF YOUR UNIVERSAL LASER DETECTOR
This unit is gasket sealed for water and dust protection. Use a soft,
dry cloth to remove any dirt or moisture from the instrument before
storage. Do not use benzene, paint thinner, or other solvents to clean
the instrument. Remove battery before long-term storage of
the instrument.
7. SPECIFICATIONS
Dimensions: 6.6" h x 3" w x 1" d (169mm x 76mm x 25mm)
Weight: 10 oz. (275g)
Range: up to 2000' (610m)
Beam Detection Sensitivity: Fine, ± .75mm; Medium, ± 1.5mm;
Coarse, ± 3mm
(sensitivity based on standard conditions with most lasers; may vary
slightly due to make, manufacturer, beam size, or working conditions)
Readout: LCD, LD400-front and rear windows; LD100N-single window
Power: One 9-volt battery; provides 3 months of typical usage
Fig. 2
