Laspaziale S2 - Page 27

espresso coffee machines
LSI 022 - Rev. 00 - Ed. 12/2015
27
L P
H
DIMENSIONS AND WEIGHT
S2
1 GR 2 GR 3 GR SPAZIO
L 460 700 930 540
H 520 520 520 520
P 530 530 530 530
WEIGHT KGS 41 65 82 57
POWER SUPPLY RATING AND ABSORPTION
S2
1 GR 2 GR 3 GR SPAZIO
VOLT 220/240 220/240 220/240/400 220/240
HZ 50/60 50/60 50/60 50/60
W 2200 3900 4500 3000
W+ 3000 - 6500 3800
The ‘W+’ symbol refers to the machine’s power with upgraded heating element.
Fig. 14
