Laspaziale S2 - 1 General Description of the Machine

espresso coffee machines
LSI 022 - Rev. 00 - Ed. 12/2015
4
1. GENERAL DESCRIPTION OF THE MACHINE
LEGEND
43
1 2
3
00
00
00
00
00
00
00
2
6
16
17
15
14
11
10
9
8
7
6
5
13 12
1. Top cup grid
2. Steam delivery knob
3. Touchpad
4. Hot water dispensing knob
5. 2-cup filter holder
6. Steam wand
7. Drip tray grid
8. Water drip tray
9. Main on/off switch
10. Electric cup warmer button
11. Adjustable foot
12. Opening for gas burner inspection
13. Gauge
14. Piezoelectric lighter for gas (o ptional)
15. Control knob for gas delivery (optional)
16. 1-cup filter holder
17. Hot water output
Fig. 1
