Preparations
13.04.99
YACE0059
7
☞
−
The unit can be operated safely up to an ambient temperature of 40°C
−
Depending on the loading of the refrigeration system, a temporary shut-off can
occur, especially in case of an ambient temperature of over 35°C.
Additionally a higher ambient temperature results in less refrigerating capacity.
−
When starting up the refrigeration system after a longer time, it can take up to 30
min, depending on the ambient temperature and the unit type, until the nominal
refrigerating capacity is reached.
5.2 Filling and emptying
Filling
−
Close the drain cock.
−
Fill baths up to a maximum level of 20 mm below the bath
bridge.
−
Optimum operation at 20-40 mm below the bath bridge.
−
Operation is possible down to 60 mm below the bath bridge.
−
The low-level cut-out operates approx. 90 mm below the
bath bridge!
☞
−
When using thermal oils it is necessary to allow for an expansion of approx.
8 %/100 °C.
−
When operating with an external consumer the total expansion takes place in the
bath!
